H1-UV-3200

EPSON I3200 Printhead Printer

H1-UV-3200 is a high resolution, great efficiency and long working life UV printer with 1.8m printing width and 3pcs Epson I3200 printhead. It prints with All CMYK/CMYK+W+CMYK optiona, which is widely used in Advertising, Wallpaper, Decoration etc. Imported UV curing ink is friendly to environment.

Send Inquiry

Send Email

Wechat:+86 15515715397

Whatsapp:+86 15515715397

Feature Specification Video Application Inquiry

Feature

Five-color printing (CMYK+W) makes the prints delicate and realistic.

Using international standard new UV ink, very environmental.

High-quality output, widely used in: advertising film, transparent film.

Using efficient UV-LED technology, it can be dried immediately after printing.

Color + white + color 3 layers of the picture, pictures can be beautifully rendered.

Compatible with different kinds of printing software.Photoprint,Maintop and Onyx is optional.

Specification

Model	H1-UV
Printhead	EPSON I3200-U1
Printhead Quantity	3
Resolution	3200DPI
Print Width	1800mm
Platform width	2000mm
Ink Type	LED-UV Environmental Curing ink
Ink Color	All CMYK/CMYK+W+CMYK optional
Color Management	ICC or density curve
Color gamut	16.7million
RIP Software	Maintop, FlexiPRINT, ONYX, etc.
Application	Advertising film, transparent film, PET & PVC, ultra-transparent and other advertising decorative materials.
Image Format	JPG, TIF, BMP, PDF, etc.
Printhead Cleaning	Automatic Cleaning, Automatic Flash Spray Moisturizing Function
Power Supply	50/60 HZ, 220V, 10A
Operation System	Win7 64bit, Win10 64bit
Transmit Port	Giga-bit Ethernet Port
Working Environment	Temperature: 15℃-30℃ Humidity: 35％-65％
Dimension	2970×945×1421mm
Weight	430KG
Print Speed	6 PASS	15㎡/h
	8 PASS	10㎡/h
